MercuryPro

Industrial grade probing systems

MercuryPro performs reliable and accurate measurements in harsh chemical and temperature conditions from -50°C to +140°C.

Fully designed and assembled in France

Main features

Wireless

Real time monitoring

From 0.001mBar to 5 Bar absolute

LiSOCl2 battery - 1month lifespan @1sample/s

1s to 24 hours sampling time

32MB memory. Up to 1M data points

Cortex-M4 core

72MHz (90DMIPS)

USB type C connectivity

High temperature range

The judicious selection of components and materials make MercuryPro capable to endure temperatures ranging from -50°C to +140°C while acquiring data.

High temperature range

The judicious selection of components and materials make MercuryPro capable to endure temperatures ranging from -80°C to +150°C while acquiring data.

Long Range connectivity

The integrated wireless module can establish a point-to-point data stream up to 30 meters to a nearby gateway. Therefore, it is no longer needed to use a pass-through cable while MercuryPro collects data within the equipment.

Bluetooth connectivity

The integrated Bluetooth LE 5.0 module can establish a point-to-point data stream up to 5 meters to a nearby computer. Therefore, it is no longer needed to use a pass-through cable while MercuryPro collects data within the equipment.

Pressure resilient

Thanks to its industrial grade Stainless Steel enclosure, MercuryPro can withstand environmental pressures ranging from 0.001mBar up to 5Bar while operating.

Pressure resilient

Thanks to its industrial grade Stainless Steel enclosure, MercuryPro can withstand environmental pressures ranging from 0.001mBar up to 3Bar while operating.

Lithium Battery

Depending on specific requirements, MercuryPro can employ either rechargeable lithium-ion batteries or utilize conventional 1200mAh LiSOCl2 non-rechargeable batteries to expand the operational temperature range.

Overall, up-to 30 days of continuous data acquisition can be performed in one single charge.

Lithium Battery

Depending on specific requirements, MercuryPro can employ either rechargeable lithium-ion batteries or utilize conventional 1200mAh LiSOCl2 non-rechargeable batteries to expand the operational temperature range.

Overall, up-to 30 days of continuous data acquisition can be performed in one single charge.

Data sampling

With MercuryPro you can adjust the data sampling period within a range spanning from 1 second to 24 hours. This feature facilitates a nuanced balance between data set precision, memory utilization, and battery consumption.

Data sampling

With MercuryPro you can adjust the data sampling period within a range spanning from 1 second to 24 hours. This feature facilitates a nuanced balance between data set precision, memory utilization, and battery consumption.

High storage capacity

MercuryPro incorporates a 32Mbits flash memory chip, enabling the probe to accommodate up to 1 million data points (or 10 days of continuous acquisition @1sample/s). Additionally, it integrates the newest intelligent data handling software designed to mitigate the risk of data loss during operation.

High storage capacity

MercuryPro incorporates a 128Mbits flash memory chip, enabling the probe to accommodate up to 1 million data points (or 10 days of continuous acquisition @1sample/s). Additionally, it integrates the newest intelligent data handling software designed to mitigate the risk of data loss during operation.

Processing unit

MercuryPro incorporates a robust ARM Cortex M4 microcontroller which efficiently manages CPU-intensive tasks while simultaneously reducing power consumption.

Processing unit

MercuryPro incorporates a robust ARM Cortex M4 microcontroller which efficiently manages CPU-intensive tasks while simultaneously reducing power consumption.

USB type C

The use of a USB Type-C connector facilitates rapid connection and data retrieval from the MercuryPro datalogger via the software user interface. Consequently an extra base station is no longer mandatory.

USB type C

The use of a USB Type-C connector facilitates rapid connection and data retrieval from the MercuryPro datalogger via the software user interface. Consequently an extra base station is no longer mandatory.

Technical data

Parameter

Value

Conditions

Temperature

-50°C ... +140°C

+- 0.05°C

Pressure

0.001mBar ... 5Bar

+- 0.001mBar

Wireless

30m range

Open air

Sampling period

1sample/s ... 1sample/24hours



Battery lifespan

30 days @1sample/s

Wireless OFF

3 days @1sample/s

Wireless ON

Battery types

Lithium-ion - 1 200mAh

-10°C ... +60°C

LiSOCl2 - 1 200mAh

-50°C ... +140°C

Memory

32Mbits flash - 1M data points



Connectivity

USB type C / Wireless



IP Rating

IP68



Material

316L Stainless Steel



Interested in knowing more about MercuryPro?
